Double standing seam roofing machine F3 is used for making double standing seam lock for the roofing panels that are used for installation of the double standing seam roofing. The double standing seam roofing is widely used because it’s impossible for the water to get under the closed double standing roofing panels in the places of their contact with each other, thanks to lock’s special shape. The special shape means that double standing seam panels cover each other in the places of their contact, and after their installation on the roof it will be closed using special double standing seam closing tools (manual tool for closing double standing seam lock and electric machine for closing double standing seam lock). The advantage of this Standing seam machine is possibility to change the width of the standing seam roofing panels in very simple way. There’s a special screw at the one side of this standing seam machine and turning it around the operator can change the width of the panels. So the adjustment of the standing seam roofing machine doesn’t take a lot of time for the operator and let him use his working time more effectively. This double standing seam roofing machine is good for making double standing seam panels from different kinds of metals (galvanized steel, steel coated with copper, zinc, titanium, etc.) This standing seam roofing machine has six pairs of rolls which form the shape of the double standing seam roofing panels. This machine could be produced for using with 220V or 380V electric lines. You can also purchase with roofing seam machine: additional pair of rolls for making ribs on the roofing panels; additional pair of rolls for making bended panels with a big radius of bending; cutting knife; metal decoiler; manual tool for closing seam lock; electric machine for closing seam lock; sheet metal cut to length machine; It’s easy to work with our double standing seam roofing machine right on the place of the double standing seam roof installation, thanks to the small weight and not huge sizes of this standing seam machine. It’s let the owner of this roofing machine to save money not spending them on renting additional places for making double standing seam roofing panels, storage them and transport to the place of their installation. Our enterprise has started producing of this double standing seam roofing machine since 2005 so we have great experience in doing our job and can propose you a great solution for your business. To get more information about the price of this double standing seam roofing machine and the way it could be delivered to your location just contact us. We will give you all the information you need.
Material width 250–700mm :: The material thickness Steel - 0,8мм, aluminium - 1,5мм :: Power 380V(220V) :: Engine power 1.1/1.5 (kW)
Plate rolling machine is used for bending pipes from the metal sheet with maximum length 1.3m and maximum thickness 1.5mm. Pipe production takes place by rolling the sheet metal between the rollers of the plate rolling machine. The upper roller of the plate rolling machine is mobile, so lowering or raising it the operator could set the radius of the pipe. There is a special adjusting screw on the plate rolling machine to change the position of the upper roller. Rollers of the plate rolling machine are made from the high-carbon steel. The diameter of the rollers is 72mm. All the rollers of the roller machine are connected to the engine through gears, so their rotation is simultaneous and uniform. It provides better quality of the products. The plate rolling machine is used for making pipes for ventilation systems, drainage systems, chimneys, etc. The upper roller of the plate rolling machine is removable so it lets the operator to bend fully closed pipes with this plate bending machine and remove it after producing process. According to the wishes of our customers we can make manual or electric variant of this plate rolling machine. Pipe-producing process includes following phases: At first the sheet metal is cut with manual shear or electric guillotine on sizes to be appropriate for working with plate rolling machine. The operator makes pipe lock using bending machine or ventilation lock forming machine Plate rolling machine forms tube with necessary size and diameter. Seam closing machine or mallet lets to close pipe lock so it the last phase in pipe-forming process. If it’s necessary, the pipe could be bended with special elbow making machine. This machine is produced for using with 380V electric lines. This plate rolling machine is often purchased with additional machines such as: manual bending machine, lock forming machine, manual swaging machine, electric swaging machine, manual lock closing machine, electric lock closing machine, manual elbow making machine, electric elbow making machine. Our enterprise has started to produce this kind of the plate rolling machines since 2004 so we have great experience in doing our job and can propose you a great solution for your business. To get information about price of this plate rolling machine and the way it could be delivered to your location just contact us. We will give you all the information you need.
Material width 1.3m :: The material thickness 1.5mm :: The diameter of the pattern 72mm :: Power 380V :: Engine power 1.1 (kW)
On the base of the electric elbow machine EEM-150 we designed elbow forming machine EEM-200 that could work with the pipes not only in the range 80-150mm but also in the range 150-200mm (with the upper lock on the pipes). Elbow forming machine EEM-200 is used for crimping elbows from round and rectangular pipes that are used in process of assembling ventilation and drainage systems. The corrugated elbow looks fancy and it could be produced from the pipes with different diameters. There are three types of elbow forming machines we make: Elbow forming machine EEM-150 for the pipes from 80mm to 150mm diameter. Elbow forming machine EEM-200 for the pipes from 80mm to 200mm diameter. Elbow forming machine EEM-250 for the pipes from 80mm to 250mm diameter. This elbow forming machine EEM-200 crimps pipes in the range from 80 to 150mm with up or down pipe lock and it crimps pipes in the range 150-200mm with upper lock on the pipes Elbow forming machine EEM-200 is electric so it doesn’t need any air or oil system to work. Electric consumption is 1.5 kW/hour for this elbow forming machine. The needed voltage is 380V. It could be used in environment with temperature from -5 to +45 Celsius degrees. Elbow forming machine EEM-200 can produce corrugated elbows from the pipes with different diameters thanks to special nozzles. The standard set of nozzles includes three dimensions which you can choose by your own. Also you can purchase additional nozzles so they will let you to crimp any sizes of downspout elbows you want. To change one nozzle to another one it takes the operator of the elbow forming machine EEM-200 less than 5 minutes. The process of one elbow producing takes less than 1 minute for the elbow forming machine EEM-200. While working nozzles don’t damage outside part of the pipes so you can use coated pipes for producing elbows with our elbow forming machine EEM-200 This elbow forming machine EEM-200 is very simple to use and it will help you to make high quality products. Our enterprise has started to produce this kind of the elbow forming machine EEM-200 since 2010 so we have great experience in doing our job and can propose a great solution to your business. To get information about price of this elbow forming machine EEM-200 and the way it could be delivered to your location just contact us. We will give you all the information you need.
The material thickness 0.6mm :: The diameter of the pattern 80-200mm :: Power 380V :: Engine power 1.5-2kW
Manual elbow machine MEM-150 forms elbows from round pipes that are used in process of assembling ventilation and drainage systems. The corrugated elbow looks fancy and it could be produced from the pipes with different diameters. There are two types of the Manual elbow machines we make: Manual elbow machine MEM-150 for the pipes from 90mm to 150mm diameter. Manual elbow machine MEM-180 for the pipes from 90mm to 180mm diameter. This Manual elbow machine bends elbows from the pipes in the range from 90 to 150mm. The elbow machine MEM-150 is manual so it doesn’t need electricity to work. Manual elbow machine can produce corrugated elbows from the pipes with different diameters thanks to special nozzles. The standard set of nozzles includes three dimensions which you can choose by your own. Also you can purchase additional nozzles so they will let you to make any sizes of downspout elbows you want. To change one nozzle to another one it takes the operator of the manual elbow machine about 5 minutes. While working nozzlesdon’t damage outside part of the pipes so you can use coated pipes for producing elbows with our manual elbow forming machine. This manual elbow forming machine is very simple to use and it will help you to make high quality products. Our enterprisehas started to produce this kind of the manual elbow forming machines since 2008 so we have great experience in doing our job and can propose the great solution to your business. To get information about the price of this manual elbowmachine and the way it could be delivered to your location just contact us. We will give you all the information you need.
The material thickness 0.7mm :: The diameter of the pattern 90-150mm
We are the group of engineers and qualified specialist as: turners, millers, welders, mechanics. We are manufacturers. The love and pride for our job consolidate us. We make machines and equipment for working with metal sheets from 0.3 till 2.0 mm. We produce electric elbow making machines, roofing seam machines, manual elbow making machines, manual shears, sheet metal cut to length machines, manual bending machines, segment sheet metal benders, rib bending machines, lock forming machines, lock closing machines, metal decoilers, swaging machines, beading machines, pipe bending machines, rolling machines.
Sometimes I’m asked: “Why the name of our company is Evolutioner?”. The answer is simple- we are contra revolution but for Evolution! The evolution has one special thing. It’s not only in quality but in quantity. Everything that remains – is the best. During 10 years of our work we have made more than 1000 machines. We have great experience, we have made all the mistakes we could make, and now we have ready solution for you to be the first!
Corner notcher NM-3 is used by enterprises who specialize in manufacturing of facade cassettes with different configurations and complexity. It allows you to optimize the preparing process, saving time on the corner punching operations of the future facade cassette of the required shape. This corner notcher is equipped with a special tool, consisting of a die and a punch, and makes it possible to punch a complex angle of the facade cassette in just one operation. Corner of NM-3 façade cassette consists of several 90 degrees angles and radius groove, which prevents possible deformation of the metal in the corner of the façade cassette during future bendings. Corner notcher NM-3 is also equipped with special equipment for cutting an oval hole for fixation bolts on the façade cassette. So, using this equipment, our customer can cut both: a complex corner of the cassette and the fixation bolt hole in one operation without wasting time on doing it on different machines and saving time and money on preparing cutting and punching works. We use special tool steel to make dies of punching press. Those dies are tempered to get necessary hardness and working resistance. To get necessary roughness of corner notcher working tool we use special grinding machines. Corner notcher NM-3 is manual driven so not require connection to electrical networks or air supply systems. Corner notcher NM-3 is driven by a special handle that transmits the force to the working mechanism of the machine. When using the punching press, it must be installed on a flat surface-table and fixed with special clamps or fastening mechanisms to prevent the machine from moving during operation. On request, it is possible to manufacture corner notchers to produce shapes of cassettes with different configurations according to customer preferences
The material thickness 1.2mm
Round duct seaming machine RDSM 1300x1.2 is used for closing operation of round pipe standing seam lock in round duct systems, drainage, ventilation and air conditioning systems production. The machine finds its application in workshops of thin metal products production, manufacturing companies of ventilation and air conditioning systems, construction companies whose work is related to sheet metal and manufacturing of different diameter pipes. To work with round duct seaming machine RDSM 1300x1.2 sheet metal pipe has to be pre-fabricated. To get blanks for pipe production you need at first to cut metal sheet in necessary dimensions using guillotine, plasma cutter, cut-to-length slitting machine or cross cutting knife from bending machine. After you have to make standing seam pipe lock on two parallels sides of blank. You can use bending machine, folding machine or ventilation lock forming HVAC machine to make this operation. Next step, using three or four rolls plate forming machine you can get round pipe with necessary diameter from flat metal sheet. And as final step to close lock of pipe with round duct seaming machine RDSM 1300x1.2 of our fabrication. Round duct seaming machine RDSM 1300x1.2 has rotating roll which is driven by special rotating handle. With closed pressing mechanism of machine pipe is going between mechanism and roll so step per step pipe lock is closing. If thickness of metal is too high so closing operation can be done in two times. Round duct seeming machine with such design lets to work with 1300mm pipes in one step and 2600 mm in two closing steps. As per request we can make machine with 1500-1600mm working length. Machine can work with maximum metal thickness 1.2mm. In standard design we make machine with 90mm shaft diameter so minimum pipes diameter you can work with is more than 90 mm. As per request we can make machine with shaft diameter less than 90mm but in this case maximum metal thickness would be less than 1.2mm Round duct seaming machine RDSM 1300x1.2 is equipped with special clamping eccentric mechanism which makes possible to adjust clamping force one time for necessary metal thickness and simply use clamping handle to close and open it without setting it up each time. It saves time while working with machine. The machine is manual so it doesn’t need any air or electricity to work. To get more information about Round duct seaming machine RDSM 1300x1.2 we produce please contact our sales department.
Material width 1300mm :: The material thickness 1.2mm
Sliding clip formers are used to produce fixation sliding clips for double standing seam roofing panels. Before installation roofing panels have to be made using roll former roofing machines. After finishing of panels production and preparing roofing works panels can be installed on roofing place with special fixation clips. Those clips, depending on design, could be fixed or sliding ones. Fixed clip has simple and cheap design so it can be good for small roofs that doesn’t have long length panels. Sliding clip are good for big roofs with different designs and long-length panels. Sliding clips can move and self-find perfect position so not be damaged and safe for roof while temperature expansions. We offer punching presses for making both fixed and sliding clips. For sliding expansion clips productions there have three presses to be used. First sliding clip bottom part press is used for punching bottom part of sliding clip with fixation round holes and connection oval hole. At the same time this press cuts metal strip with necessary length. Blank for clip production is easy to get using manual guillotine or cut-to-length slitting machine. Second sliding clip bottom part bender is used for bending of sliding clip bottom part to 90 degrees angle. So, after this operation bottom part is ready. Third clip former makes top part of sliding clip at the same time forming and bending it. After producing bottom and top part of sliding clip you can easily connect it to one working sliding clip. So using sliding clip formers that we offer you can easily make expansion clip and use it while double standing seam roofing installation without any unnecessary deformations. Maximum metal thickness you can work with -1mm. To get more information about sliding clip former we produce please contact our sales department.
The material thickness 1 mm
Pan & box brakes SM3-1270x2 is used for bending metal sheets up to 1270mm length and 2mm thickness. The main difference of ours bending machine from other models is segmented three bars: upper bar and bending bar segmented, and also segmented bottom bar. So it lets to bend difficult shapes elements with reverse bends. This additional third segmented bar makes bending machine more functional and lets the user to expand range of elements he can make. Pan & box brakes has pedal mechanism to make work of one operator more convenient and freer his hands while metal fixing process. In standard set pan & box brakes SM3-1270x2 goes with three segmented bars. Height of upper segments is 30mm, lifting height of upper beam is 40mm. Also in standard set with machine goes four position angle limiter to make production of same angle elements more easier and side notch segments to bend boxes with inside bends. As additional options you can get: upper segments 45mm heigh instead of 30mm; tempering of segments (30 points of hardness instead of 12 points) cross cutting knife multifunctional acceptance table to make production of same sizes elements much easier As an option we can make upper segments as L shape and 100-120mm height Maximum bending angle of machine is 135 degrees. Segmented bending machine SM3-1270x2 is equipped with 11 segments of different length: 400мм, 270мм, 200мм, 100мм,75мм, 50мм, 45мм, 40мм, 35мм, 30мм, 25мм so it lets to bend different sizes boxes and elements. So pan & box brakes SM3-1270x2 with three bars segmented is perfect solution for customers who makes different elements such as façade cassettes and boxes with reverse bends, companies whose field of work is ventilation elements production and air conditioning systems production, construction companies and others who work with metal sheets and produce different elements from it. To get more information about segmented bending machines we produce please contact our sales department.
Material width 370kg :: The material thickness 2mm
